Machine vision in focus
| Sensor | GMAX2509 |
| Image Sensor | 10.5 mm × 5.4 mm CMOS |
| Shutter | Global |
| Resolution | 4192 × 2160 |
| Frame Rate | 120 fps |
| Bit Depth | 12 bit |
| Mono/Color | Mono |
| Pixel Size | 2.5 μm × 2.5 μm |
| Pixel | 9 MP |
| S/N Ratio | 36 dB |
| Dynamic Range | 62 dB |
| Image Format | Mono8/10/12 |
| ROI | Support |
| X Flip | Support |
| Y Flip | Support |
| Gain | Analog gain: 1× ～ 2×, Digital gain: 1× ～ 100× |
| Exposure Time | 2 μs ~ 5 s |
| Trigger Mode | Software Trigger/Hardware Trigger/Free Run Mode |
| SPC | Support |
| User Setting | Support two sets of user-defined configurations |
| Port | CXP-6 |
| GPIO Interface | 1× Opto-isolated input, 1× Opto-isolated output, 1× configurable input and output |
| Lens Mount | C-mount |
| Power Supply | DC 24V power supply via 6 Hirose interface, support PoCXP |
| Power Consumption | 24 V ≈ 6.9 W |
| Product Dimensions | 50 mm × 50 mm × 44.7 mm (Non including rear case connector) |
| Net Weight | 240 g |
| Storage Temperature | -30℃~+80℃ |
| Operating Temperature | -30℃~+40℃ |
| Bit depth | 12 bit |
|---|---|
| Dynamic range | 62 dB |
| Exposure time | 2 us ~ 5 s |
| Frame rate | 120 fps |
| Gain | Analog gain: 1x ~ 2x, Digital gain: 1x ~ 100x |
| Gpio interface | 1x Opto-isolated input, 1x Opto-isolated output, 1x configurable input and output |
| Image format | Mono8/10/12 |
| Image sensor | 10.5 mm x 5.4 mm CMOS |
| Lens mount | C-mount |
| Pixel | 9 MP |
| Pixel size | 2.5 um x 2.5 um |
| Port | CXP-6 |
| Power consumption | 24 V ≈ 6.9 W |
| Power supply | DC 24V power supply via 6 Hirose interface，support PoCXP |
| Resolution | 4192 x 2160 |
| Roi | Support |
| Sensor | GMAX2509 |
| Shutter | Global |
| Spc | Support |
| Storage temperature | -30℃~+80℃ |
| Trigger mode | Software Trigger/Hardware Trigger/Free Run Mode |
| User setting | Support two sets of user-defined configurations |
| X flip | Support |
| Y flip | Support |
| Mono-color | Mono |
| S/n ratio | 36 dB |
