Machine vision in focus
| Sensor | 8K |
| Image Sensor | CMOS |
| Shutter | Global |
| Resolution | 8192 × 3 |
| Line Rate | 48 kHz |
| Bit Depth | 12 |
| Mono/Color | Color |
| Pixel Size | 7 μm × 7 μm |
| Pixel | 8192 × 3 |
| S/N Ratio | 40 dB |
| Dynamic Range | 63.3 dB |
| Image Format | RGB8 |
| Binning | Support |
| ROI | Support |
| X Flip | Support |
| Gain | 1~32 |
| Gamma | From 0 to 4, support LUT |
| Exposure Time | 4μS~100mS |
| Trigger Mode | Software Trigger/Hardware Trigger/Free Run Mode |
| FPN | Support |
| User Setting | Support two sets of user-defined configurations |
| Port | 10Gige |
| GPIO Interface | 4 differential input, output, and 1 GPIO input, output, |
| Lens Mount | M72 |
| Power Supply | DC 12~24V power supply via 12-pin Hirose connector |
| Power Consumption | 14W |
| Product Dimensions | 80mm×80mm×48.2mm(Not including rear case connector) |
| Net Weight | 520 g |
| Storage Temperature | -30℃~+80℃ |
| Operating Temperature | 0℃～+50℃ |
| Binning | Support |
|---|---|
| Bit depth | 12 |
| Dynamic range | 63.3 dB |
| Exposure time | 4us~100mS |
| Fpn | Support |
| Gain | 1~32 |
| Gamma | From 0 to 4，support LUT |
| Gpio interface | 4 differential input, output, and 1 GPIO input, output, |
| Image format | RGB8 |
| Image sensor | CMOS |
| Lens mount | M72 |
| Line-rate | 48 kHz |
| Pixel | 8192 x 3 |
| Pixel size | 7 um x 7 um |
| Port | 10GigE |
| Power consumption | 14W |
| Power supply | DC 12~24V power supply via 12-pin Hirose connector |
| Resolution | 8192 x 3 |
| Roi | Support |
| Sensor | 8K |
| Shutter | Global |
| Storage temperature | -30℃~+80℃ |
| Trigger mode | Software Trigger/Hardware Trigger/Free Run Mode |
| User setting | Support two sets of user-defined configurations |
| X flip | Support |
| Mono-color | Color |
| S/n ratio | 40 dB |
