R5050MG-16M-RGG02E

Resolution 2368 × 1792
Max. Frame rate 45 fps
Shutter Mode Global
Mono/Color Mono
Lens Mount M12
Trigger Mode Software trigger/External trigger/Free run modes, etc.
Software EasyID
Certifications CE, UKCA, KC
Function lD: Code 39/Code 93/Code128/CodaBar/EAN8/EAN13/UPCA/UPCE/ITF25/2of5（Industrial2of5）/standard25/GS1-128 etc. and 2D: Data Matrix/MQR/GS1 DM/GS1QR etc.; Quality Evaluation: ISO/IEC 29158(AIM-DPM), ISO/IEC 15415, ISO/IEC 15416）
Focal Length 16mm
Light Source Type Red
Focus Control auto focus
Working Distance 100mm-1500mm
Field of View (FOV) 96mm × 72 mm@WD200mm
Max. Read Speed 90 codes/s
Max. Operating Speed 3m/s
Min. Resolution 1D code 0.04 mm/ 2D code 0.04 mm
Connector 2 Industrial connectors support GigE and GPIO
Network Port GigE
GPIO Interface RS232, 2 Opto-isolated inputs and 3 Opto-isolated outputs
Communication Mode RS232, Ethernet
Communication protocol SDK, TCP Client, TCP Server, FTP, RS232, Profinet、Modbus、EtherNet/IP、MC(SLMP)、FINS/UDP、FINS/TCP
LED Indicator Power,Ethernet,Status,Result
Power Supply 9~26VDC, 2A input, suitable for industrial environment
Power Consumption <18 W(light included)
Product Dimensions 82mm×55mm×50.7mm (not including connector)
Net Weight <350 g
Protection IP65
Casing Material Aluminum R5050MG-08M-WGG02;R5050MG-08M-RGG02;R5050MG-12M-WGG02;R5050MG-12M-RGG02;R5050MG-16M-WGG02;R5050MG-16M-RGG02;R5050MG-08M-WGG02E;R5050MG-08M-RGG02E;R5050MG-12M-WGG02E;R5050MG-12M-RGG02E;R5050MG-16M-WGG02E;R5050MG-16M-RGG02E;oy + Front cover
Operating Temperature -20℃～+50℃
Operating Humidity 20%～95%(no condensation)
Storage Temperature -30℃～+70℃
Add to Quote
Category: Tag: Brand:

Description

  • Light-integrated design makes red/white/blue illumination optional, support control separately
  • Support different focal lengths, electrical auto focus and one-click auto training
  • GigE interface, IP65 protection level
  • Abundant IO interfaces such as Ethernet, RS232, GPIO, support multiple communication protocols
  • Support various code formats and evaluations of code quality
  • Built-in deep-learning algorithms and multi-parameters polling to ensure effects of complex applications

Dimensions

Downloads

Additional information

Connector

2 Industrial connectors support GigE and GPIO
Field of view

96mm x 72 mm@WD200mm
Focus control

Auto focus
Gpio interface

RS232, 2 Opto-isolated inputs and 3 Opto-isolated outputs
Lens mount

M12
Power consumption

<18 W(light included)
Power supply

9~26VDC, 2A input, suitable for industrial environment
Resolution

2368 x 1792
Storage temperature

-30℃~+70℃
Trigger mode

Software trigger/External trigger/Free run modes, etc.
Working distance

100mm-1500mm
Mono-color

Mono
Max. frame rate

45 fps
Shutter mode

Global
Software

EasyID
Certifications

CE，UKCA，KC
Function
Light source type

Red
Max. read speed

90 codes/s
Max. operating speed

3m/s
Min. resolution

1D code 0.04 mm/ 2D code 0.04 mm
Network port

GigE
Communication mode

RS232, Ethernet
Communication protocol

SDK，TCP Client，TCP Server，FTP，RS232，Profinet、Modbus、EtherNet/IP、MC（SLMP）、FINS/UDP、FINS/TCP
Led indicator

Power,Ethernet,Status,Result
Protection

IP65
Casing material
Operating humidity

20%~95%(no condensation)
